203
SJ63 AJ+, SJ63 AJ 229043AAA
Platform Section 5 – Procedures
P2 (Grey) Master Controller: SMB1-105
Pin Wire Function Input/Output Type I/O Name Label
1 16 Drive Forward Analog Output PWM01 PWM02
2 15 Drive Reverse Analog Output PWM00 PWM01
3 31 Riser Up Analog Output PWM07 PWM08
4 30 Riser Down Analog Output PWM06 PWM07
5 14 Boom Up Analog Output PWM05 PWM06
6 13 Boom Down Analog Output PWM04 PWM05
7 41 Platform Level Up Analog Output PWM11 PWM12
8 63AJ Boom Down Throttle Analog Output PWM10 PWM11
9 38 Fly Boom In Analog Output PWM09 PWM10
10 39 Fly Boom Out Analog Output PWM08 PWM09
11 Not Used -- --
12 42 Proportional Flow Analog Output PWM14 PWM15
13 32 Turret Rotate Left Analog Output PWM02 PWM03
14 55 Fuel level float sw Digital Input P4B DIN02
15 14B Main Boom Up Digital Input P72 DIN04
16 13B Main Boom Dn Digital Input P77 DIN06
17 32B Turret Rotate L Digital Input P7C DIN08
18 10A Emergency Pump / Enable Digital Input PF0 DIN10
19 29 Fly Boom In LS (Hi Speed Drive) Digital Input P25 DIN12
20 12 Platform key position Digital Input P82 DIN14
21 38B Telescope Retract Digital Input P92 DIN16
22 41B Platform Level Up Digital Input PC0 DIN18
23 Not Used PWM13 PWM14
24 33 Turret Rotate Right Analog Output PWM03 PWM04
25 17 Direction Sensing Digital Input P49 DIN01
26 34B Jib Down Digital Input P4D DIN03
27 28 Tilt Switch Active Digital Input P74 DIN05
28 35B Jib Up Digital Input P7A DIN07
29 59
Main Boom Cradled LS (Hi Speed
Drive)
Digital Input P7E DIN09
30 57 Engine Start Request Digital Input PF2 DIN11
31 10 Base key position Digital Input P20 DIN13
32 33B Turret Rotate R Digital Input P90 DIN15
33 39B Telescope Extend Digital Input P94 DIN17
34 Not Used -- --
35 40 Platform Level Down Analog Output PWM12 PWM13
