SM ALFOplus2 - Page 137

MN.00356.E - 003 135
Tab.45 - 21200 - 23600 MHz band - ITU-R F.637-3 - Annex 1 - Go-return 1232 MHz -
Frequency carrier limits
Tab.46 - 21200 - 23600 MHz band - ITU-R F.637-3 - Annex 4 - Go-return 1200 MHz -
Frequency carrier limits
56 22282.75 22562.75 23290.75 23570.75
112 22310.75 22534.75 23318.75 23542.75
FREQUENCY RANGE: 21200 - 23600 MHz - GO-RETURN: 1232 MHz - ITU-R F.637-3 - Annex 1
SUB BAND 1
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
14 21193 21675 22425 22907
28 21200 21668 22432 22900
56 21214 21654 22446 22886
112 21242 21626 22474 22858
SUB BAND 2
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
14 21557 22011 22789 23243
28 21564 22004 22796 23236
56 21578 21990 22810 23222
112 21606 21962 22838 23194
SUB BAND 3
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
14 21893 22375 23125 23607
28 21900 22368 23132 23600
56 21914 22354 23146 23586
112 21942 22326 21174 23558
FREQUENCY RANGE: 21200 - 23600 MHz - GO-RETURN: 1200 MHz - ITU-R F.637-3 - Annex 4
SUB BAND 1
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
14 21184 21666 22384 22866
28 21191 21659 22391 22859
56 21205 21645 22405 22845
