Tab.47 - 21200 - 23600 MHz band - FCC CFR Title 47 Part 101 - Go-return 1200 MHz - Frequency
carrier limits
112 21233 21617 22433 22817
SUB BAND 2
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
14 21598 22052 22798 23252
28 21605 22045 22805 23245
56 21619 22031 22819 23231
112 21647 22003 22847 23203
SUB BAND 3
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
14 21934 22416 23134 23616
28 21941 22409 23141 23609
56 21955 22395 23155 23595
112 21983 22367 23183 23567
FREQUENCY RANGE: 21200 - 23600 MHz - GO-RETURN: 1200 MHz - FCC CFR Title 47 Part 101 -
405.5-400-403.5 MHz RF Filter tuning range
SUB BAND 1
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
20 21187 21663 22387 22863
30 21192 21658 22392 22858
40 21197 21653 22397 22853
50 21202 21548 23402 22848
SUB BAND 2
Channel
bandwidth
[MHz]
Lower half of the band Higher half of the band
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
Lowest Frequency
Carrier [MHz]
Highest Frequency
Carrier [MHz]
20 21601 22049 22801 23249
30 21606 22044 22806 23244
40 21611 22039 22811 23239
50 21616 22034 22816 23254
SUB BAND 2
