Field Name Description
Use the following Static IP address Use this section to manually declare the Static IP information provided by your ISP.
WAN IP Address Enter the static WAN IPV4 Address.
WAN Subnet Mask Enter the static Subnet Mask.
WAN gateway IP address Enter the static Gateway IP address.
Advanced DMZ (Optional) Check this option to enable Advanced DMZ on the WAN service.*
NON DMZ IP Address
(Optional)
Broadcast a specific vendor ID for the DHCP server to accept the device.
NON DMZ Net Mask Enter a secondary LAN IP address for the gateway. e.g. 192.168.2.1
Obtain an IPv6 address automatically When you wish the ISP to automatically assign the WAN IP to the gateway.
Dhcpv6 Address Assignment (IANA) Select this option for CPE to receive WAN IP from ISP.
Dhcpv6 Prefix Delegation (IAPD) Select this option for CPE to generate WAN IP’s prefix from server rest by MAC address.
Use the following Static IPv6 address Use this section to manually declare v6 the Static IP information provided by your ISP.
WAN IPv6 Address/Prefix Length Enter the IP address / prefix length
WAN Next-Hop IPv6 Address Enter the IP address of
* For additional info see the SmartRG Support site’s knowledgebase.
Enter the NAT Settings.
No selections are required. All settings are optional.
