The individual fields on this screen are defined as follows:
Field Name Description
Port Number Displays the statistics specifically for Port 1, or both ports if Bonded
In Octets Total quantity of received Octets
Out Octets Total quantity of transmitted Octets
In Packets Total quantity of received Packets
Out Packets Total quantity of transmitted Packets
In OAM Cells Total quantity of received OAM Cells
Out OAM Cells Total quantity of transmitted OAM Cells
In ASM Cells Total quantity of received ASM Cells
Out ASM Cells Total quantity of transmitted ASM Cells
In Packet Errors Total quantity of received Packet Errors
In Cell Errors Total quantity of received Cell Errors
xDSL
Device Info -> Statistics -> xDSL displays the DSL statistics for your SmartRG Gateway. All xDSL (VDSL or ADSL) interfaces configured for your
SmartRG gateway are included. You are also able to reset these counters by selecting the Reset Statistics button located on the xTM screen as
shown below.
Use the Reset Statistics button near the bottom of the screen to reset these counters.
Also featured is an xDSL Bit Error Rate (BER) test which determines the quality of the xDSL connection. Scroll to the bottom of the table of
statistics and click xDSL BER Test. The test transfers idle cells containing a known pattern and compares the received data with this known
pattern. Comparison errors are then tabulated and displayed. The duration of the test is selectable from the drop-down menu at the test screen.
Selectable values range from 1-360 seconds.
The following figure and table depict and explain the fields on the screen..
