SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2014 77
Field Name Description
Last Member Query Interval
Enter the maximum response time within which the host must respond to the Out of Sequence query from the
router. (Default = 1000ms)
IGMP uses this value when router receives and IGMPv2 Leave report indicating at least one host wants to leave
the group. Upon receiving the Leave report, the router confirms the interface is not configured for IGMP
Immediate Leave. If not, the router sends the out-of-sequence query.
Robustness Value
[2-7] Enter the value representing the complexity of the query. The greater the value, the more robust the
query.
Maximum Multicast Groups Maxim number of groups allowed.
Maximum Multicast Data
Sources (for IGMP v3)
[1-24] Maximum data sources allowed.
Maximum Multicast Group
Members
The maximum number of multicast groups that can be joined on a port or group of ports.
Fast leave [Enabled, Disabled] If enabled, the IGMP proxy removes group member immediately without sending a query.
LAN to LAN (Intra LAN)
Multicast
Check this option to permit a multicast data source on the LAN side and IGMP snooping enabled.
Membership Join Immediate
(IPTV)
When enabled, clients do not send a join report and will have faster join at startup but only by a few
milliseconds.
Basic
This page allows you to configure basic features of the Wi-Fi LAN interface. You can enable or disable the Wi-Fi LAN interface, hide the network
from active scans, set the Wi-Fi network name (also known as SSID) and restrict the channel set based on country requirements.
After selecting Wireless -> Basic from the left navigation bar you may modify settings as desired.
Click Apply/Save to commit your settings.
