The individual fields on this screen are defined as follows:
Field Name Description
Mode Displays the service type (ADSL_2plus, VDSL2)
Traffic Type Displays the connection type (ATM, PTM, ETH
Status Displays the status of the connection (Up, NoSignal, Initializing)
Link Power State Link output power state
Line Coding (Trellis) (Downstream/Upstream) Displays the state of Trellis Coded Modulation (On, Off)
SNR Margin (db) (Downstream/Upstream) Signal to Noise Ratio
Attenuation (db) (Downstream/Upstream) Estimate of average loop attenuation
Output Power (dBm) (Downstream/Upstream) Transmit power from the gateway to the DSL loop.
