Field Name Description
Attainable Rate (Kbps) (Downstream/ Upstream) The typically obtainable sync rate.
PhyR Status [Inactive, Active] Physical Layer Retransmission feature status. (Downstream/ Upstream)
Rate (Kbps) (Path 0/1, Downstream/Upstream) Current sync rate
MSGc (# of bytes in overhead channel
message)
(Path 0/1, Downstream/Upstream)
B (# of bytes in Mux Data Frame) (Path 0/1, Downstream/Upstream)
M (# of Mux Data Frames in FEC Data Frame) (Path 0/1, Downstream/Upstream)
T (Mux Data Frames over sync bytes) (Path 0/1, Downstream/Upstream)
R (# of check bytes in FEC Data Frame) (Path 0/1, Downstream/Upstream)
S (ratio of FEC over PMD Data Frame length) (Path 0/1, Downstream/Upstream)
L (# of bits in PMD Data Frame) (Path 0/1, Downstream/Upstream)
D (interleaver depth) (Path 0/1, Downstream/Upstream)
Delay (msec) (Path 0/1, Downstream/Upstream)
INP (DMT symbol) (Path 0/1, Downstream/Upstream)
Super Frames (Path 0/1, Downstream/Upstream) Total number of super frames.
Super Frame Errors
(Path 0/1, Downstream/Upstream)
Total number of super frames received with errors.
RS Words
(Path 0/1, Downstream/Upstream)
Total number of Reed-Solomon code errors.
RS Correctable Errors
(Path 0/1, Downstream/Upstream)
Total number of Reed-Solomon with correctable errors.
RS Uncorrectable Errors
(Path 0/1, Downstream/Upstream)
Total number of Reed-Solomon with uncorrectable errors.
RS Codewords Received
(Path 0/1, Downstream/Upstream)
Total number of Reed-Solomon Codewords received.
RS Codewords Corrected
(Path 0/1, Downstream/Upstream)
Total number of Reed-Solomon Codewords corrected.
RS Codewords Uncorrected (Path 0/1, Downstream/Upstream) Total number of Reed-Solomon Codewords Uncorrected
HEC Errors (Path 0/1, Downstream/Upstream) Total number of Header Error Checksum errors
OCD Errors (Path 0/1, Downstream/Upstream) Total number of Out-of-Cell Delineation errors
LCD Errors (Path 0/1, Downstream/Upstream) Total number of Loss of Cell Delineation errors
Total Cells (Path 0/1, Downstream/Upstream) Total number of Cells
Data Cells (Path 0/1, Downstream/Upstream) Total number of Data Cells
Bit Errors (Path 0/1, Downstream/Upstream) Total number of Bit errors
Total ES (Downstream/Upstream) Total number of Errored Seconds
Total SES (Downstream/ Upstream) Total number of Severely Errored Seconds
Total UAS (Downstream/Upstream) Total number of Unavailable Seconds
