Introduction Features and Specifications
Wireless Version (Later-Models)
1— VGA (video graphics array) Connector
2— LAN (local area network) Jack
3— USB (universal serial bus) Jacks (2)
4— Audio (head phone) Jack
5— DC Power Supply Input Jack
6— Fan Filter
7— Scope Auxiliary Connector
8— Channel 4 Jack
9— Channel 3 Jack
10—Channel 2 Jack
11—Channel 1 Jack
12—Common Ground Jack
Figure 2-3 Top view, wireless model
