Chapter 16 Maintenance
This section covers how to care for your diagnostic tool.
16.1 Cleaning the Touch Screen
The touch screen can be cleaned with a soft cloth and alcohol or a mild window cleaner.
Do not use any abrasive cleansers or automotive chemicals on the touch screen.
16.2 Calibrating the Touch Screen
The sensitivity and accuracy of the touch screen should be calibrated before you begin using your
diagnostic tool. Adjustments can be made to the touch screen calibration to maintain your
personal settings. The touch screen can also be set to recognize the stylus being held in place for
five seconds as a right-click of a mouse. Both procedures are explained below.
z To calibrate the touch screen:
1. From the Windows toolbar select Start > All Programs > Hampshire TSHARC Control
Panel to open the touch screen dialog box (Figure 16-1).
Figure 16-1
Sample Hampshire TSHARC Control Panel window
2. Select the Calibration tab.
3. Select Configure to open the Calibration Options dialog box.
4. Check 20% in the Offset field on the right-hand side of the dialog box, scroll down and select
20 Point Calibration on the left-hand side of the screen.
