System Settings Operations Paired Devices
The Hardware Status indicators in the lower-right corner of the Home screen provide a quick
reference to wireless device operations. The background color of the status indicator icon
represents the condition of the wireless connectivity to that device. Icon status is shown in the
table below:
13.1.1 Pairing the Wireless Scan Module
For detailed information on the use and pairing of the Scan Module, see "Pairing The Scan
Module‚" on page 55.
Hardware
Icon
Background
Color
Condition Action
Scan Module
Red Not Paired
Pair the Scan Module to the Diagnostic Tool.
See "Pairing The Scan Module‚" on page 55 for
instructions.
Grey
Paired, but Not
Communicating
You may have moved out of range. Move the
Diagnostic Tool closer to the Scan Module to
reestablish communications. If connectivity is
not restored, perform the "Recovery
Procedure‚" on page 61.
Blue
Paired and
Communicating
Hardware status is good and Bluetooth should
be functional. Verify that the green Bluetooth
LED on the front of the Scan Module is flashing.
If there is no connectivity, perform the
"Recovery Procedure‚" on page 61.
Green USB Cable Connected Indicates the USB cable is connected.
Gray
USB Cable Not
Connected
Indicates the USB cable is not connected or
connected but not allowing communication

Snap-On VERUS Specifications

General

Manufacturer	Snap-On
Model	VERUS
Function	Diagnostics, Programming, and Analysis
Display	Touchscreen LCD
Connectivity	USB, Wi-Fi
Software Updates	Yes, via Wi-Fi
Power Source	AC Adapter
Compatibility	Various vehicle makes and models (check specifications for details)
