178
Maintenance Scan Module
4. When the “finished successfully” message displays, select OK to reboot the system.
The Windows system reseal program automatically runs on start up and a dialog box displays.
Once the reseal completes, the dialog box closes, Windows starts, and the diagnostic tool is
ready for use.
If you receive an error message while starting the software, the license key may need to be
updated or replaced. Contact your sales representative or Customer Care.
i After using the Snap-on System Restore software, the diagnostic tool is restored to original factory
condition. In addition, if you have purchased and installed any of the “Bundle” updates, the most
current Snap-on Bundle update will also be re-installed. However, any additional software that you
installed will need to be reloaded onto the system after a System Restore. Contact your sales
representative or Customer Care for additional information.
16.7 Scan Module
When using the wireless Scan Module, make sure to do the following:
• Check the housing, wiring, and connectors for dirt and damage before and after each use.
• At the end of each working day, clean the housing, wiring, and connectors with a clean damp
cloth.
Do not use any abrasive cleansers or automotive chemicals on the Scan Module.
16.7.1 Replacing the Protective Handgrip
The soft protective handgrip that covers the outer edges of the Scan Module is easily replaced
should it become worn or damaged. Contact your sales representative for replacement parts.
z To replace the protective handgrip:
1. Disconnect the data cable, and any other cables, if attached to the Scan Module.
2. From the bottom of the Scan Module, gently lift up and out on one side of the handgrip to free
it from Scan Module housing.
3. Repeat step 2 to loosen the other side of the handgrip.
4. Lift the handgrip off of the Scan Module housing.
i The handgrip tapers toward the front of the Scan Module housing. Make sure the replacement
handgrip is correctly oriented before attempting to install it.
5. Fit the new handgrip over the top, data cable end, of the Scan Module housing.
6. With your fingers, work the new handgrip onto the Scan Module housing from top to bottom.
Make sure the tabs on the handgrip fit into the grooves on the housing.
