85
Guided Component Test Operations Operations
Selecting the Close icon (red box with an X) when viewing the meter in a separate window
closes the meter and returns you to the Guided Component Test screen.
3. Select the Meter icon a third time to close the separate window and return to the standard
meter view as shown in Figure 7-9.
Select Exit from the toolbar to close meter view and return to the Guided
Component Test
screen.
Connecting to a Test Vehicle
Before performing a test, you must connect the meter test leads to the vehicle. Certain guided
component tests require the use of specific leads. Information on specific leads and other
connecting information displays on the initial test screen. Follow the on-screen connection
instructions in the test procedure to connect the test leads.
Performing a Test
Once you connect the test leads to the vehicle, you can proceed with testing.
z To perform guided component tests:
1. Follow the instructions displayed in the test procedure section.
2. Gesture sweep to view all of the instructions and follow the on-screen procedures.
3. Select the View Meter hyperlink to display test results.
4. Refer to the on-screen information to verify test results.
Refer to Operations on page 131 for additional information on working with the View Meter
window.
