166
Operation on LCD
Region Australia A Australia B Australia C
New
Zealand
Standarad
Code
Name
AS4777_2022
_A
AS4777_2022
_B
AS4777_2022
_C
New
Zealand
Setting
Range
Recover-
FH
50.15 Hz 50.15 Hz 50.15 Hz 50.15 Hz
Recover-
FL
47.5 Hz 47.5 Hz 47.5 Hz 47.5 Hz
Start-VH 253 V 253 V 253 V 253 V
Start-VL 205 V 205 V 205 V 198 V
Start-FH 50.15 Hz 50.15 Hz 50.15 Hz 50.15 Hz
Start-FL 47.5 Hz 47.5 Hz 47.5 Hz 47.5 Hz
Setting Grid Parameters
In Grid Parameters interface, the protection value of grid voltage and frequency
can be set. The default setting will be adjusted by default under the current safety
regulations.
The display content will be displayed according to the requirements of local laws
and regulations. Please refer to the contents displayed on the inverter screen.
Setting Charger
The inverter is compatible with the lithium battery. You can set Max Charge, Max
DisCharge and Charger upper limit to control the charge and discharge of the
battery.
Default current: 50A; range: 0~50A.
======Charger======
Charger upper limit
100%
======Charger======
>Max Charge
Current:
50A
Figure 9-44 Setting battery charging and discharging limits
Setting Export Control If Necessary
This function allows the inverter to control the output power to the grid. The user value
set must be less than the maximum value. If the user does not want to supply power to the
grid, set it to 0.
