173
Table 9-4 Setting items in Pu Function
Pu Functiion
Items
ResponseV1
ResponseV2
ResponseV3
ResponseV4
3Tau
SetPuPower1
SetPuPower2
SetPuPower3
SetPuPower4
3Tau _Charge
Pu Type
Setting FVRT Function (apply to 50549)
The items in the FVRT interface will be adjusted in accordance with the local
safety requirements and law regulations, casual modification is prohibited.
Default VacUpper: 265 V
Default VacLower: 115 V
The default parameters adjust with the “Safety Code” selected.
====FVRT Function====
VacUpper
00.0V
====FVRT Function====
VacLower
00.0V
====FVRT Function====
Function Control
> Enable <
Figure 9-59 Enabling FVRT function
Setting Power Limit
Set Proportion in the Power Limit interface to limit the power of the AC output
of the inverter.
Default proportion: 1.00 (the max value)
If you set 0.5, the AC output of the inverter will be limited to 50%
=====Power Limit=====
> Proportion
1.00
Figure 9-60 Setting proportion in power limit interface
