II
About This Manual
Scope of Validity
This manual is an integral part of X3-IES system. It describes the
installation, electrical connection, commissioning, maintenance and
troubleshooting of the product. Please read it carefully before operating.
This X3-IES system includes a X3-IES series inverter and a T-BAT-SYS-HV-
S50E.
X3-IES series inverter model list:
X3-IES-4K X3-IES-5K X3-IES-6K
X3-IES-8K X3-IES-10K X3-IES-12K
X3-IES-15K
Components of T-BAT-SYS-HV-S50E:
BMS Battery Module
TBMS-MCS0800E TP-HS50E
Note:
"X3-IES system" is the name of three-phase residential energy storage
system.
"X3-IES series inverter" (hereafter referred to as an "inverter") refers to the
energy storage inverter that supports photovoltaic grid-connected.
“4K"means the rated output power is 4kW.
"T-BAT-SYS-HV-S50E” (hereafter referred to as an "T-BAT-SYS") is the name
of battery system. lt includes a TBMS-MCS0800E, a TP-HS50E (s), a base (s),
a cover and a series box.
"TBMS-MCS0800E" (hereafter referred to as an "BMS") is an electronic
system manages a rechargeable battery.
"TP-HS50E" (hereafter referred to as an "battery module(s)") is a type of
electrical battery which can charge or discharge loads.
"Base" is an accsssory of the battery system. lt is installed under the battery
module (s).
"Cover" is an accessory of the battery system. lt is installed on the top
battery module of the expansion battery tower.
"Series box" is designed to connect the second tower in series through
BMS wiring.
