SolaX Power X3-IES Series User Manual

42
Preparation before Installation
Two Towers
Option D
Option E
Option F
1281 mm
>300 mm
809 mm
1127 mm
>300 mm
963 mm
>300 mm
1281 mm
1127 mm
Option G
1599 mm
1127 mm
>300 mm
Figure 4-4 Installation options for two towers
Table 4-1 Net weight and dimensions of components
Option
A
Option
B
Option
C
Option D Option E Option F Option G
Left
tower
Right
tower
Left
tower
Right
tower
Left
tower
Right
tower
Left
tower
Right
tower
Inverter 1 1 1 1 / 1 / 1 / 1 /
BMS 1 1 1 1 / 1 / 1 / 1 /
Battery
module(s)
2 3 4 2 2 1 3 2 3 3 3
Base 1 1 1 1 1 1 1 1 1 1 1
Series
box
/ / / / 1 / 1 / 1 / 1
Cover / / / / 1 / 1 / 1 / 1
* A base support (s) is (are) necessary if the wall mounting is selected for all installation
options.
