Preparation before Installation
Net Weight and Dimensions of X3-IES system
• One Tower
Table 4-2 Net weight and dimensions of X3-IES system in one tower
Option A Option B Option C
Net weight [kg] 144.2 191.2 238.2
Dimension [mm] 730 × 1281 × 209.5 730 × 1599 × 209.5 730 × 1917 × 209.5
• Two Towers
Table 4-3 Net weight and dimensions of X3-IES system in two towers
Option D Option E
Left Tower Right Tower Left Tower Right Tower
Net weight [kg] 144.2 100.5 97.2 147.5
Dimensions
[mm]
730 × 1281 × 209.5 730 × 809 × 150 730 × 963 × 209.5 730 × 1127 × 150
Figure 4-5
Table 4-4 Net weight and dimensions of X3-IES system in two towers
Option F Option G
Left Tower Right Tower Left Tower Right Tower
Net weight [kg] 144.2 147.5 191.2 147.5
Dimensions
[mm]
730 × 1281 × 209.5 730 × 1127 × 150 730 × 1599 × 209.5 730 × 1127 × 150
NOTICE!
• The maximum net weight of an inverter (37kg) is taken as an example.
• The net weight of inverters of different powers differs. Please check the specific net
weight of the X3-IES series inverter when calculating the total weight of the devices
of X3-IES system.
• Please consider the distance between the left tower and right tower under limited
installation space.
Table 4-5 Net weight and dimensions of the inverter
Model
X3-IES-
4K
X3-IES-
5K
X3-IES-
6K
X3-IES-
8K
X3-IES-10K X3-IES-12K X3-IES-15K
Net weight
[kg]
35 35 35 35 35 37 37
Dimension
[mm]
717 * 405 * 209.5
