67
Mechanical Installation
Figure 6-20 Knocking expansion tubes into the wall
As for securing
brackets, refer to
Step 8.
Figure 6-21 Tightening the BMS brackets
NOTICE!
• An electric drill dust collector is recommended.
• To prevent dust from being released into the hot plug when drilling holes, users
may use the package bag of the device or other materials to fully cover the battery
module.
To Next Page
