Activate the required result
( ).
Go to details using the
icon.
After the icon has been
selected, the option of record
editing is also available in ac-
cordance with section 5.1.2b,
steps .
Description of other function
icons
returning to the previous
screen
returning to the main menu
5.2 Recorder memory
5.2.1 microSD Memory Card
Removable microSD HC card is the primary place of data storage. The following are saved on it:
recorded measurement data,
screenshot files.
The top bar shows the status of the card and its free space available.
To ensure proper operation of the meter and prevent data loss, do not:
remove the memory card during recording. Removal of the card may result in ending the record-
ing process, damage of data recorded, and in some cases, damage to the entire structure of
files saved on the card.
modify or delete files stored on the card or store your own files on it. If after inserting the card the
meter detects an error in the file system, the memory format panel is shown to perform format-
ting of the card. Only after formatting (which removes all files) it will be possible to reuse the card
in the device.
In addition, before removing the card from the meter (e.g. to read the data by Sonel Analysis) it is
recommended to turn the meter off, to save all cached data.
MicroSD memory card may be formatted from the user interface level. Go to Analyser settings, and
then select the Memory section, where the user can format the selected memory (see also section
5.1.1).
5.2.2 USB external memory (flash drive)
Connecting an external USB stick allows user to:
copy selected files with screenshot from microSD memory card to the memory stick,
save the log file of the meter, in case of an error in the device in order to perform an analysis in
the service of the manufacturer,
update the firmware of the device.
