MPI-540 – USER MANUAL
90
3.8.3 Measurements using UNI-Schuko adapter (WS-03 and WS-04)
WARNING
 During measurements of insulation resistance, dangerous voltage up to 500 V
occurs at the ends of test leads of the meter.
 It is forbidden to disconnect test leads before the measurement is completed.
Failure to obey the above instruction will lead to electric shock with high volt-
age and make it impossible to discharge the tested object.
Select item R
ISO
, to call up the
measurement menu.
Connect WS-03 adapter or
WS-04 adapter with UNI-Schuko
outlet plug.
The meter detects this fact auto-
matically and changes the ap-
pearance of the screen.
Enter the measurement settings in accordance with section 3.8.1
