Soundcraft Vi6™ User GuidePage 12 - 2
SETUP
[SETUP] opens the configuration page, which contains the central oscillator and the Talkback Send and
Talk Back return configuration of the Soundcraft VI6™.
Figure 12-2: Setup Page.
OSC Section
HINT: The oscillator can also be patched to the Input Channels by using the {OSC} key in the Input Channel
VST screen.
<PINK NOISE>
Sets the waveform to pink noise.
<WHITE NOISE>
Sets the waveform to white noise.
<SINE>
Sets the waveform to sine.
<OSC to BUS>
Feeds the Oscillator to the preconfigured Busses, which are selected in the Bus Assign page (Figure 12-3).
<OSC to TB>
The oscillator signal is routed to the TB Bus and replaces the TB signal.
FREQ field
If the oscillator is set to SINE the Encoder adjusts the Frequency in the range 20 Hz – 20kHz.
BUS ASSIGN field
Its {VST config button} opens the Buss Assign page (see Figure 12-3).
GAIN field
Encoder adjusts the oscillator level in the Range – inf to +12 dB. {ON} enables the oscillator.
