Soundcraft Vi6™ User Guide Page 6 - 3
Adjusting A Matrix Send Level
Ensure that the [ALL BUSSES] key is NOT selected.
Press the [SOLO/SEL] on a matrix master. All the input bays will change to the matrix contributions view
and the Faderglow™ illuminates with the matrix colour. The input strip [ON] keys act as ON for the matrix
send signals. The fader adjusts the contribution level of the desired source (1..32).
MATRIX CONFIGURATION
This screen opens on all 4 input bays after pressing SOLO/SEL on a matrix master.
Figure 6-3:Matrix Configuration Page
SOURCE field
Displays the patched source.
The key opens the Matrix patch configuration page - see chapter 11.
