SPECTRA PRECISION FOCUS 2 SERIES TOTAL STATION USER GUIDE
A – Design Road Line Data
147
Raw data
This is the format of data transmitted from the instrument to the computer.
Record format: example of FOCUS 2 data
Data transferred to PC Description
CO,FOCUS2 Raw data The type of transmitted data
CO,SAMPLE1 File name
CO,Description Job description
CO,Client
CO,Comments
CO,Downloaded 2007-03-02 22:40:59 Download date and time
CO,Software: Pre-install version:07.03.02 Software version number
CO,Instrument: FOCUS 2 S15101 Serial number of instrument
CO,Dist Units: Metres Distance unit
CO,Angle Units: DDDMMSS Angle unit
CO,Zero azimuth: North AZ Zero azimuth
CO,VA: Zenith VA Zero azimuth
CO,Coord Order: NEZ Coordinate order
CO,HA Raw data: HA zero to BS HA
CO,Projection correction: OFF Projection correction
CO,C&R correction: ON C&R correction
CO,Tilt Correction: OFF Tilt correction
CO,SAMPLE1 <JOB> Created 2007-03-02
22:37:25
JOB creation time
MP,1,,10.000,10.000,1.000,VM
MP,5,,50.000,50.000,5.000,MP
Manually entered coordinate record
Record format: pointID, N/E,E/N, Z, Code
CO,Temp:20.0 C Press:1013.2 hPa Prism:-30mm
2007.03.02 22:38:26
Temperature, pressure, prism offset, date, time
ST,1,,5,,1.600,45.0000,0.0000 Station data record
Record format: Station pointID, Backsight pointID, height of
instrument, azimuth (AZ), horizontal angle (HA)
F1,5,1.800,1.999,176.5958,99.2715, 23:26:28 Result of backsight point F1 orientation
Record format: pointID, target height, slope distance,
horizontal angle, vertical angle, time
SS,2,1.800,1.088,359.5959,62.4302,
22:38:45,MA
Sideshot point measurement data
Record format: pointID, target height, slope distance, HA,
VA, code
MP,99,,20.000,3.000,6.000, Manually entered coordinate record
Record format: pointID, N/E,E/N, Z, Code
CO,Pt:100 SO deltas N: E: Z:-3.131 Comment containing Stakeout residuals
SO,,,1.800,1.089,5.0432,84.5528, 22:40:28, Stakeout data record
Record format: ,,, target height, slope distance, HA, VA, time
