SPECTRA PRECISION FOCUS 2 SERIES TOTAL STATION USER GUIDE
5 – Applications
99
DAT key
When the [DAT] key is pressed in the Basic Measurement screen or in observation screens in functions
such as Stakeout, 2Pt RefLine, and so on, the data in the current job is displayed.
Hold the key down for one second in the Basic Measurement screen or an observation screen to
display the Data Type screen. Through this screen you can change the type of data that is assigned to
the
[DAT] key.
To change the type of data that is assigned to [DAT], in the Menu screen, select 6.1 Sec and then select
[5] (Data).
For more information, see Data, page 112.
USR 1/USR2 keys
If a certain function is used frequently in the field, it can be assigned to the [USR1] or [USR2] key.
Whenever a
[USR] key is pressed, the function that is predefined is activated directly.
The following functions can be assigned to the [USR] keys:
• Input HT
• BS Check
• TGT
• Cogo
• Offset
• Program
• Temp&Press
• Note
• Point Laser
• Direction Laser
• (none)
1. In the Basic Measurement screen, press [USR1]/[USR2] for 1 sec. The function list for the [USR] key
appears.
2. Press [v]/[^] to highlight the function and then press [REC/ENT] to select it.
Note – If an item on the list has an arrow beside it, and this item is selected, the whole menu is
assigned to the
[USR] key. To assign a specific function from the sub-menu, press [v]/[^] to highlight the
function. Then press
[REC/ENT] to select it.
The screen returns to the Basic Measurement screen—the current predefined function is indicated
by an asterisk (*) beside the function name. Once a function is assigned to a
[USR] key, it is activated
directly whenever that key is pressed in the Basic Measurement screen.
