SPECTRA PRECISION FOCUS 2 SERIES TOTAL STATION USER GUIDE
5 – Applications
83
3. Sight the second point and press [MSR1] or [MSR2]. The distances between the first and second
point are displayed.
4. To change display screens, press [v].
5. To record the distance and angle information as a comment record, press [REC/ENT] in the 1/2 or
2/2 observation screen.
Default point numbers are displayed (STN=0, PT=1, PT=2, and so on). These point numbers can
be changed.
6. After recording, the display returns to the Mlm Cont. screen. Sight the third point and press
[MSR1] or [MSR2]. The distances between the second and third point are displayed.
7. Press [REC/ENT] to record the distances between the second and third point.
8. Repeat the procedure to calculate and record the distance between the third and fourth point,
and so on.
rSD Slope distance between two points
rVD Vertical distance between two points
rHD Horizontal distance between two points
rAZ Azimuth from first point to second point
rV% Percentage of grade (rVD/rHD) × 100%
rGD Vertical grade (rHD/rVD)
