Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
13
◎ Make sure it is disconnected from the mains
prior to wiring
Or it may cause risk of electric shock.
◎ The wiring can only be performed by
trained and qualified electricians
Or it may cause risk of electric shock.
◎ Always keep the iAStar-S8 elevated
integrated drive controller properly
grounded at its grounding terminal E
Or it may cause risk of electric shock.
◎ Avoid confusing main circuit input terminals
and output terminals of elevator integrated
drive controller
Or it may cause risk of property damage and/or
explosion.
◎ Never make terminal ○
+
1/ ○
+
2 and ○
-
be
shorted.
or it may case risk of fire and explosion
◎ Make sure the cover is placed in position
prior to switching on
Or it may cause risk of electric shock and/or
explosion.
◎ Don’t use soggy hands operating elevator
integrated drive controller
Or it may cause risk of electric shock
◎ At completion of wiring the emergency stop
safety circuit, carefully check and make sure
all the wirings are correct
Or it ma
case risk of hazard.
◎ When switching on a elevator integrated
drive controller which has been stored for
more than 2 years, a voltage regulator is
needed to supply it by increasing the voltage
gradually
Or it may cause risk of electric shock and
ex
losion
v
◎ Avoid faulty operation when elevator
integrated drive controller is running
Or it may cause risk of high-voltage electric
shock.
◎ After it is switched off, the inside of elevator
integrated drive controller may remain
dangerous high voltage for a certain period,
don’t open the cover or touch connection
terminals
Or it may cause risk of high-voltage electric
shock.
Danger
Danger
Danger
