STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
152
F232
Filtering time for feedback
signal of encoder
0 1～30 ms
F233
Feedback direction of
encoder
1 0／1 ×
1：positive sequence
0
：
negative sequence
F234 Motor phase sequence 1 0／1 ×
1：positive direction
0：negative direction
F235
Motor no-load current
coefficient
32.00 0.00～60.00 ％
Unnecessary to set up
nomally
F236 PWM carrier frequency 6.000
1.100～
11.000
kHz
Do not adjust this
parameter under
normal circumstances
F237 PWM carrier width 0
0.000～
1.000
kHz
Do not adjust this
parameter under
normal circumstances
F238 Regulator mode 1 0/1/2/3 ×
Do not adjust this
parameter under
normal circumstances
F239 Output torque limit 175 0～200 ％
Do not adjust this
parameter under
normal circumstances
F240 Input voltage of inverter 380 0～460 V
F241 Nominal power of inverter KW
This is a read-only
query data
F242 Phase angle of encoder 0.0 0.0～360.0 Degree
F243
Zero position correction of
encoder
0 0/2 ×
Set 2 for zero point
correction
F244 Spare 10002
No. Name Factor
y Setup
Scope Unit Remarks
F245
Selection of
F246~F255 parameter
function
0 0～65535 ×
Modify this parameter, then
F246～F255 will have different
meanings
When F245=0, F246~F255 have the following meanings
F246
Overheating protection
time for radiator
50
000～
65535
0.01s
Default protection in case of
radiator overheating for more
than 0.5 second
F247
Overspeed protection
coefficient
12000 0～65535 0.01%
The default overspeed protection
threshold is 120%
F248
Overspeed protection
time
100 0～65535 0.01s
Default protection in case of the
speed surpasses F247 value for 1
second
