Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
155
F255
decelerating
overvoltage threshold
of inverter
750 0800 V
Inverter stop decelerating and
maintain the current speed if bus
voltage is more than the setting
value during the deceleration
process, then continue to
decelerate once the voltage drop.
When F245=3, F246~F255 have the following meanings
F246 Current loop P 140 35280 ×
Current loop Kp (no need to
modify)
F247 Current loop I 100 25200 ×
Current loop Ki(no need to
modify)
F248 Current loop D 0 0200 ×
Current loop Kd(no need to
modify)
F249 spare ×
F250 spare ×
F251 spare ×
F252 spare ×
F253 Spare
F254 Torque direction 0 0/1 0:positive 1:negtive
F255 Spare
When F245=4, F246~F255 have the following meanings
F246 Software version x Read-only
F247 ID No 0 X Read-only
F248 ID No 1 X Read-only
F249 ID No 2 x Read-only
F250 ID No 3 x Read-only
F251 ID No 4 X Read-only
F252 ID No 5 X Read-only
F253 Inverter rated current 0.1A Read-only
F254
Rated current of
inverter current sensor
A Read-only
F255
Motor power
coefficient
200 50~400 %
Set the max power output,
generally do not need to change
When F245=5, F246~F255 have the following meanings
F246 Stator resistor
0.001
ohm
Stator resistor of asynchronous
motor
F247 Rotor resistor
0.001
ohm
Rotor resistor of asynchronous
motor
F248 Stator inductor
0.0001
H
Stator inductor of asynchronous
motor
F249 Rotor inductor
0.0001
H
Rotor inductor of asynchronous
motor
