Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
158
The following is the example explaining the setting method of parameter F10 and F11
Suppose that there are two elevators in parallel connection in a building. Elevator A
serves 15 floors above ground only while Elevator B serves 15 floors above ground and
2 floors underground.
For Elevator A, the total floor number is 15; offset floor is 2; the address of lowest floor
call and registration begin with 3.
For Elevator B, the total floor number is 17; offset floor is 0, the address of lowest floor
call and registration begin with 1.
Note: if the by-pass floors of elevators within the group control or in parallel
connection are different, it is required to artificially make the service floors by
installing the leveling plate to the by-pass floors of those elevators. In this way do
guarantee the same floor sequencing among the elevators within the group control
or in parallel connection.
Example as the following table
Table 7.2 example for F10 and F11 parameter setting
As show in the above table, Elevator B must install a leveling plate at the by-pass
position of second floor to keep its floor number as same as Elevator A.
For elevator A, the total floor number is 4; floor offset is 1; the address of first floor call and
registration begin with 2. Display setting: first floor=70; second floor=2;
Third floor=3; forth floor=4.
Parking floor: G (stand for the specific floor address) –yes (Parking allowed)
2-Yes; 3-Yes; 4-Yes.
For elevator B, the total floor number is 5; floor offset is 0; the address of floor -1 call and
registration begin with 1. The address of first floor is 2.
Display setting : floor －1 =50； floor 1=70；floor 2=2；floor 3=3； floor
4=4。
Parking floor: -1- Yes；G-Yes；2-No (parking not allowed, the call and
registration of floor address 3 of elevator B is invalid)
3-Yes；4-Yes。
F12—— inspection speed. The inspection speed range from 0 to 0.63m/s
Actual
Floors
Actual
Indicatio
n
Floors
By
Elevat
or A
Fl.
addres
s
of
Elevat
or A
Set
Indications
for Elevator
A
Floors
by
Elevato
r B
Fl.
addres
s of
Elevat
or B
Set
Indication
s for
Elevator B
4 4 4 5 4 4 5 4
3 3 3 4 3 3 4 3
2 2 2 3 2 by-pass 3 2
1 G 1 2 70 1 2 70
-1 -1 -1 1 50
A
B
