F164—— load-weighing instrument type, the acquisition method of weighing signal and
compensation signal. The following table gives a list of corresponding load-weighing
instrument type, the acquisition method of different weighing signal and
compensation signal with difference F164 parameter.
F164 setting
value
Load-weighing
instrument
modle
Signal acquisition method
of light-load, heavy-load,
full-load , over-load
Acquisition method of
compensation signal
0 DTZZ-III-DC-SC Switch signal input to car
ceiling board
Input load-weighing instrument
signal through CAN, Then
calculate the final compensation
value based on the weighing
instrument signal,
F193,F194,F195
1 DTZZ-II Input the load-weighing
instrument signal through
CAN, then calculate based on
the weighing instrument
signal.
Input the load-weighing
instrument signal through CAN
2 DTZZ-II Switch signal input to car
ceiling board
Input the load-weighing
instrument signal through CAN
3 DTZZ-III-DC-SC Input the load-weighing
instrument signal through
CAN, then calculate based on
the weighing instrument
signal
Input load-weighing instrument
signal through CAN, Then
calculate the final compensation
value based on the weighing
instrument signal,
F193,F194,F195
4 none Switch signal input to car
ceiling board
Calculated the weighing
compensation value of light-load
and heavy-load based on the
light-load or heavy-load switch
signal as well as F193, F194,
F195. meanwhile, F40 set as 50%
5 Switch signal input to car
ceiling board
Input weighing instrument signal
through analog quantity.
6 Input the weighing
instrument signal through
analog quantity. And
calculate based on the
weighing instrument signal
Input weighing instrument signal
through analog quantity.
99 Switch signal input to car
ceiling board
None.
Note 1:
When F164 is 0～3 , the load-weighing device is model DTZZ-III-DC-SC or
DTZZ-II specialized for STEP corporation. The weighing signal is transmitted to
