STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
215
deceleration switch on the single level is shorter than the minimum
deceleration distance
Check the operation: the position of the downward deceleration switch on the
single level is 100mm higher than the position of the downward deceleration
switch on the single level in the well learning
Check the operation: the position of the downward deceleration switch on the
single level is 150mm lower than the position of the downward deceleration
switch on the single level in the well learning
Check at stop: the position of the downward deceleration switch on the single
level is 100mm higher than the position of the downward deceleration
switch on the single level in the well learning
Check at stop: the position of the downward deceleration switch on the single
level is 150mm lower than the position of the downward deceleration switch
on the single level in the well learning, and the deceleration switch on the
single level is not in action
In automatic operation, the upper and lower limit switches are in action at the
same time and the elevator is not at the lowest level
12
Dislocation of
upward deceleration switch 2
Check after self study or with power on: the position of the upward
deceleration switch on the double level is 3/5 higher than the story height of
the switch floor
Check the operation: the position of the upward deceleration switch on the
double level is 150mm lower than the position of the upward deceleration
switch on the double level in the well learning
Check the operation: the position of the upward deceleration switch on the
double level is 250mm higher than the position of the upward deceleration
switch on the double level in the well learning
Check at stop: the position of the upward deceleration switch on the double
level is 150mm lower than the position of the upward deceleration switch on
the double level in the well learning
Check at stop: the position of the upward deceleration switch on the double
level is 200mm higher than the position of the upward deceleration switch
on the double level in the well learning, and the deceleration switch on the
double level is not in action
Only one-grade deceleration switch installed, but two-grade deceleration
switch configured (See F182)
13
Dislocation of
downward deceleration switch 2
Check after self study or with power on: the position of the downward
deceleration switch on the double level is 3/5 higher than the story height of
the switch floor
Check the operation: the position of the downward deceleration switch on the
double level is 150mm higher than the position of the downward
deceleration switch on the double level in the well learning
Check the operation: the position of the downward deceleration switch on the
double level is 250mm lower than the position of the downward deceleration
