Instruction Manual for AS380 Series Elevator Integrated Drive Controller
216
switch on the double level in the well learning
Check at stop: the position of the downward deceleration switch on the
double level is 150mm higher than the position of the downward
deceleration switch on the double level in the well learning
Check at stop: the position of the downward deceleration switch on the
double level is 200mm lower than the position of the downward deceleration
switch on the double level in the well learning, and the deceleration switch
on the double level is not in action
Only one-grade deceleration switch installed, but two-grade deceleration
switch configured (See F182)
14
Dislocation of
upward deceleration switch 3
Check after self study or with power on: the position of the upward
deceleration switch on three levels is 3/5 higher than the story height of the
switch floor
Check the operation: the position of the upward deceleration switch on three
levels is 250mm lower than the position of the upward deceleration switch
on three levels in the well learning
Check the operation: the position of the upward deceleration switch on three
levels is 300mm higher than the position of the upward deceleration switch
on three levels in the well learning
Check at stop: the position of the upward deceleration switch on three
levels is 250mm lower than the position of the upward deceleration switch
on three levels in the well learning
Check at stop: the position of the upward deceleration switch on three
levels is 250mm higher than the position of the upward deceleration switch
on three levels in the well learning, and the deceleration switch on three
levels is not in action
Only one-grade or two-grade deceleration switch installed, but three-grade
deceleration switch configured (See F182)
15
Dislocation of
downward deceleration switch 3
Check after self study or with power on: the position of the downward
deceleration switch on three levels is 3/5 higher than the story height of the
switch floor
Check the operation: the position of the downward deceleration switch on
three levels is 250mm higher than the position of the downward deceleration
switch on three levels in the well learning
Check the operation: the position of the downward deceleration switch on
three levels is 300mm lower than the position of the downward deceleration
switch on three levels in the well learning
Check at stop: the position of the downward deceleration switch on three
levels is 250mm higher than the position of the downward deceleration
switch on three levels in the well learning
Check at stop: the position of the downward deceleration switch on three
levels is 250mm lower than the position of the downward deceleration
switch on three levels in the well learning, and the deceleration switch on
