Instruction Manual for AS380 Series Elevator Integrated Drive Controller
244
F52 Front door opening
permission 3 (opening
setup value for 33 ～ 48
floors)
65535 0～65535 ×
F191 Front door opening
permission 4 (opening
setup value for 49 ～ 64
floors)
65535 0～65535 ×
F53 Rear door opening
permission 1 (opening
setup value for 1 ～ 16
floors)
0 0～65535 ×
F54 Rear door opening
permission 2 (opening
setup value for 17 ～ 32
floors)
0 0～65535 ×
F55 Rear door opening
permission 3 (opening
setup value for 33 ～ 48
floors)
0 0～65535 ×
F192 Rear door opening
permission 4 (opening
setup value for 49 ～ 64
floors)
0 0～65535 ×
F56 Up leveling adjustment (50
to refernece value)
50 0～240 mm
F57 Down leveling adjustment
(50 to refernece value)
50 0～240 mm
F59 Zero speed brake delay 0 0～10.00 0.01s
F61 Arrival distance by arrival
gong
1200 0～4000 mm
F62 Anti-slipping limit time 32 20～45 s
F65 Base electrode lock mode 0 0～1 × 0: No base lock, 1:
output contactor off,
immediate lock
F66 With or whithout upper
and lower limt
0 0-1
0
：
no
1
：
yes
F67 With or whithout
entension board
0 0-1
0
：
no
1
：
yes
F70 Light load uplink gain
100 0-300
F71 Light load lowlink gain
100 0-300
F72 Heavy load uplink gain
100 0-300
F73 Heavy load lowlink gain
100 0-300
