Stober SI6A062 - Tab. 104 X4 A Connection Description for Resolvers; Tab. 105 X4 A Connection Description for HIPERFACE DSL Encoders

10 | Connection STOBER
122
02/2019 | ID 442728.05
Resolver
Socket Pin Designation Function
8|7|6|5|4|3|2|1
15|14|13|12|11|10|
9
1 S4 Sin+ Sin input
2 R1 Ref− Reference potential for pin 6
3 S3 Cos+ Cos input
4 — —
5 — —
6 R2 Ref+ Resolver excitation signal
7 1TP1 Reserve
8 — —
9 S2 Sin− Reference potential for pin 1
10 — —
11 S1 Cos− Reference potential for pin 3
12 — —
13 — —
14 1TP2 Reserve
15 — —
Tab. 104: X4A connection description for resolvers
HIPERFACE DSL encoders
Socket Pin Designation Function
8|7|6|5|4|3|2|1
15|14|13|12|11|10|
9
1 — —
2 DSL− Inverse HIPERFACE DSL signal (motor
temperature sensor evaluation over DSL
communication)
3 — —
4 DSL+ HIPERFACE DSL signal (motor temperature
sensor evaluation over DSL communication)
5 — —
6 — —
7 — —
8 — —
9 — —
10 — —
11 — —
12 — —
13 — —
14 — —
15 — —
Tab. 105: X4A connection description for HIPERFACE DSL encoders
