STOBER 6 | Technical data
02/2019 | ID 442728.05
53
6.3.3 Dimensions
g
c
g
0 – 2 3
b
w
w
b
h4
h3
h1
a
h2
a
d
Fig.7: SI6 dimensional drawing
Dimension Size 0 Size 1 Size 2
5
Size 2
6
Size 3
Drive controller Width w 45 65 105
Depth d 265 286
Body height h1 343
Fastening clip height h2 15
Height incl.
fastening clips
h3 373
Total height incl.
shield connection
h4 423
Fastening holes (M5) Vertical distance a 360+2
Vertical distance to
the upper edge
b 5
Horizontal spacing of
the fastening holes
c 45
Horizontal distance
to the side edge
g 30
Tab. 41: SI6 dimensions [mm]
5
Single-axis controller
6
Double-axis controller
