STOBER 16 | Appendix
02/2019 | ID 442728.05
237
16.1.11 SPC 16 -ST-10,16
Feature Line type Value
Contact spacing — 10.16mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
55A/66A/66A
Max. conductor cross-section Flexible without end sleeve 16.0mm²
Flexible with end sleeve without plastic collar 16.0mm²
Flexible with end sleeve with plastic collar 10.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
4.0mm²
AWG according to UL/CSA 4
Min. conductor cross-section Flexible without end sleeve 0.75mm²
Flexible with end sleeve without plastic collar 0.75mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve
with plastic collar
0.75mm²
AWG according to UL/CSA 20
Insulation stripping length — 18mm
Tightening torque — —
Tab. 237: SPC 16 -ST-10,16 specification
16.1.12 ISPC 16 -ST-10,16
Feature Line type Value
Contact spacing — 10.16mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
55A/66A/66A
Max. conductor cross-section Flexible without end sleeve 16.0mm²
Flexible with end sleeve without plastic collar 16.0mm²
Flexible with end sleeve with plastic collar 10.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
4.0mm²
AWG according to UL/CSA 4
Min. conductor cross-section Flexible without end sleeve 0.75mm²
Flexible with end sleeve without plastic collar 0.75mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve
with plastic collar
0.75mm²
AWG according to UL/CSA 20
Insulation stripping length — 18mm
Tightening torque — —
Tab. 238: SPC 16 -ST-10,16 specification
