16 | Appendix STOBER
232
02/2019 | ID 442728.05
Supply module
Type X10 X11 X21 X22 X23 X100
PS6A24 SPC 16 -
ST-10,16
[}237]
BLDF 5.08
180 SN
[}234]
ISPC 5 -
STGCL-7,62
[}236]
ISPC 5 -
STGCL-7,62
[}236]
FKC 2,5 -
ST-5,08
[}234]
FMC 1,5 -
ST-3,5
[}232]
PS6A34 BUZ 10.16IT
180 MF
[}238]
BUZ 10.16IT
180 MF
[}238]
Tab. 227: Terminal specifications for the supply module
16.1.2 FMC 1,5 -ST-3,5
Feature Line type Value
Contact spacing — 3.5mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA: 8A
Max. conductor cross-section Flexible without end sleeve 1.5mm²
Flexible with end sleeve without plastic collar 1.5mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 16
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 24
Insulation stripping length — 10mm
Tightening torque — —
Tab. 228: FMC 1,5 -ST-3,5 specification
