16.1.3 BCF 3,81 180 SN
Feature Line type Value
Contact spacing — 3.81mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
16A/10A/11A
Max. conductor cross-section Flexible without end sleeve 1.5mm²
Flexible with end sleeve without plastic collar 1.0mm²
Flexible with end sleeve with plastic collar 1.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 16
Min. conductor cross-section Flexible without end sleeve 0.14mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 26
Insulation stripping length — 10mm
Tightening torque — —
Tab. 229: BCF 3,81 180 SN BK specification
16.1.4 BFL 5.08HC 180 SN
Feature Line type Value
Contact spacing — 5.08mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
16A/10A/10A
Max. conductor cross-section Flexible without end sleeve 2.5mm²
Flexible with end sleeve without plastic collar 2.5mm²
Flexible with end sleeve with plastic collar 2.5mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 12
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.2mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 26
Insulation stripping length — 10mm
Tightening torque — —
Tab. 230: BFL 5.08HC 180 SN specification
