Stober SI6A062 - 16.1.13 Buz 10.16 It 180 Mf

16 | Appendix STOBER
238
02/2019 | ID 442728.05
16.1.13 BUZ 10.16IT 180 MF
Feature Line type Value
Contact spacing — 10.16mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
61A/60A/60A
Max. conductor cross-section Flexible without end sleeve 16.0mm²
Flexible with end sleeve without plastic collar 16.0mm²
Flexible with end sleeve with plastic collar 10.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 4
Min. conductor cross-section Flexible without end sleeve 0.5mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 22
Insulation stripping length — 12mm
Tightening torque — 2.0Nm
(18Lb.inch)
Tab. 239: Specification for BUZ 10.16IT 180 MF
