STOBER 10 | Connection
02/2019 | ID 442728.05
155
10.7.3 One Cable Solution
STOBER synchronous servo motors are equipped with plug connectors as standard.
STOBER provides suitable cables in various lengths, conductor cross-sections and connector
sizes.
A motor connection as a One Cable Solution (OCS) combined with a HIPERFACE DSL encoder
requires hybrid cables which feature encoder communication and power transmission in a
shared cable.
Information
For connecting as a One Cable Solution, use exclusively hybrid cables from STOBER. The use
of unsuitable cables or poorly made connections can cause subsequent damage. For this
reason, we reserve the right to reject claims under the warranty in this case.
10.7.3.1 Connection description
Depending on the size of the motor plug connector, the hybrid cables are available in the
following designs:
§ springtec quick lock for con.15
§ speedtec quick lock for con.23 and con.40
