16 Appendix
16.1 Terminal specifications
Relevant information for projecting the connecting wiring can be taken from the following
chapters.
DIN EN 60204-1 contains basic recommendations that should be taken into account when
selecting conductors. The chapter "Conductors and cables" provides specifications for the
maximum current carrying capacity of conductors based on the way they are laid as well as tips
for derating, for example in the case of increased surrounding temperatures or lines with
multiple loaded individual conductors.
WARNING!
Risk of personal injury or material damage due to electric shock and thermal overload!
▪ Prepare the conductor ends according to the terminal specifications.
▪ In the case of pre-made cables and conductors, check the conductor ends and adjust them
if necessary.
16.1.1 Overview
The following tables clarify which specifications must be observed for which connections
depending on the type of drive controller and accessory as well as the supply module.
Drive controller
Type X2A, X2B X11, X300 X20A, X20B X22 X101, X103
SI6A061 BCF 3,81 180
SN [}233]
BLDF 5.08 180
SN [}234]
GFKC 2,5 -
ST-7,62 [}235]
ISPC 5 -
STGCL-7,62
[}236]
FMC 1,5 -
ST-3,5 [}232]
SI6A062
SI6A161
SI6A162 SPC 5 -ST-7,62
[}236]
ISPC 16 -
ST-10,16
[}237]
SI6A261
SI6A262 BFL 5.08HC
180 SN [}233]
SPC 16 -
ST-10,16
[}237]
BUZ 10.16IT
180 MF [}238]
SI6A361
Tab. 225: Terminal specifications for the base device
Safety technology
Type X12
SR6
BCF 3,81 180 SN [}233]
Tab. 226: Terminal specifications of the safety technology
