Stober SI6A062 - Maximum Operation on PS6 A34; Tab. 77 Maximum Operation on One PS6 A34 Supply Module with DL6 B21 Rear Section Module

7 | Project configuration STOBER
82
02/2019 | ID 442728.05
7.4.2 Maximum operation on PS6A34
Drive controller Quick DC-Link Limiting factor Examples
Type Self-
capacitance
C
PU
[mF]
Nominal input
current (DC)
I
1N,PU
[A]
8
Width
[mm]
Type Charging
capacity
(C
max,PU
= max.
10mF)
Nominal
output current
(I
2N,PU
= max.
42.8A)
Length of the
copper rails
[max.
1500mm]
Partial load of
50%
Partial load of
25%
SI6A061 0.18 4.2 45 DL6B10 55 devices 10 devices 32 devices 20 devices 40 devices
SI6A062 0.27 8.4 45 DL6B10 37 devices 5 devices 32 devices 10 devices 20 devices
SI6A161 0.47 10.4 65 DL6B11 21 devices 4 devices 22 devices 8 devices 16 devices
SI6A162 0.94 20.7 65 DL6B11 10 devices 2 devices 22 devices 4 devices 8 devices
SI6A261 0,94 19,0 65 DL6B11 10 devices 2 devices 22 devices 4 devices 8 devices
SI6A262 2.25 41.2 105 DL6B12 4 devices 1 device 13 devices 2 devices 3 devices
SI6A361 2.25 41.2 105 DL6B12 4 devices 1 device 13 devices 2 devices 3 devices
Tab. 77: Maximum operation on one PS6A34 supply module with DL6B21 rear section module
8
Measured value
