Stober SI6A062 - Tab. 36 X101 Electrical Data; Tab. 37 X103 Electrical Data

STOBER 6 | Technical data
02/2019 | ID 442728.05
47
6.3.1.6 Binary inputs
X101 specification for binary signals
Electrical data Binary input Value
Low level BE1 – BE4 0 – 8V
DC
High level 12 – 30V
DC
U
1max
30V
DC
I
1max
16mA
f
1max
BE1 – BE2 10kHz
BE3 – BE4 250kHz
Internal device update rate BE1 – BE4 Cycle time for the application parameterized in A150;
t
min
= 1ms;
Also applicable for binary inputs BE3 and BE4: with
timestamp correction in an accuracy range of 1µs
Max. cable length 30m
Tab. 36: X101 electrical data
X103 specification for binary signals
Electrical data Binary input Value
Low level BE6 – BE9 0 – 8V
DC
High level 12 – 30V
DC
U
1max
30V
DC
I
1max
16mA
f
1max
BE6 – BE7 10kHz
BE8 – BE9 250kHz
Internal device update rate BE6 – BE9 Cycle time for the application parameterized in A150;
t
min
= 1ms;
Also applicable for binary inputs BE8 and BE9: with
timestamp correction in an accuracy range of 1µs
Max. cable length 30m
Tab. 37: X103 electrical data
