6. Beforereturningtherollerwastecollectortotheprintblock,makesure
thatthepinsareclean.
Figure6-41Rollerwastecollectorpins
Tore-assemblethecomponents:
1. Returntherollerwastecollectortotheprintblockandscrewonthe
covering(seeFigure6-39onthepreviouspage).
2. Loosenthescrewssecuringthesuctiontube.
Figure6-42Suctiontubecorrectlypositioned
3. Lowerthesuctiontubesothattheholeinthepanelbehindthetubeis
visible,andtightenthescrewstosecurethetube.
4. Attachtheright-UV-lampassemblytotheprintblockandreconnectthe
UVpowerandfancables.
Replacing the
Roller Scraper
Youshouldreplacetherollerscraperblade—
•after1,000hoursofprinting.
•ifitdoesnoteffectivelykeeptherollerclean.
Youshouldperiodicallytesttheeffectivenessoftherollerscraperwhen
youcleantherollerwastecollector.See"CleaningtheRollerWaste
CollectorandInspectingtheRollerScraper"onpage6-33.
