MAIN MENU: SCALE (CONTINUED)
Gain or Loss Button
When the “Gain or Loss” button is pressed on
the Scale screen, Figure 5.15 will be displayed.
This will show the initial weight of the patient, the
current weight and the gain or loss of weight of the
patient.
To change the measuring values, press on the
“Lb/Kg” button.
To close the window, press on the “Close” button.
When the reset button is pressed, Figure 5.16 will
be displayed. If “Ok” is pressed, the message “Do
not touch bed” will be displayed.
When the “Do not touch bed” message disappears,
the “Gain or Loss reset success!” message will be
displayed as shown in Figure 5.17
Footboard Operation Guide
Gain or Loss
Close
lbs/Kg
Reset
Patient Weight
Initial
Current
Gain
127.1 lbs
127.1 lbs
0.0 lbs
Figure 5.15
Figure 5.16
Figure 5.17
Cancel
Ok
Reset
Gain or Loss?
Message
Close
Gain Or Loss
reset success!
Message
