www.stryker.com 2131-009-005 REV A 1-5
Return To Table of Contents
Introduction
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the
sum of the patient, mattress and accessory
weight.
550 lbs 250 kg
Bed Weight 750 lbs 340.2 kg
Overall Bed Length 90” 228,6 cm
Overall Bed
Width
Siderails Up 42” 106,7 cm
Siderails Down 41” 104,1 cm
Base Under Bed Clearance 5” 12,7 cm
Litter Patient Surface
• Width
• Length
• Length (with Optional Bed Extender)
35”
84”
90”
88,9 cm
213,4 cm
228,6 cm
Seat Section
• Depth
18.5” 47 cm
Foot Section
• Length
• Angle
29”
0° to 50°
73,7 cm
0° to 50°
Fowler Section
• Length
• Width
• Angle
36”
34” to 35”
0° to 70°
91,4 cm
86,4 cm - 88,9 cm
0° to 70°
Gatch Section
• Length
• Width
• Angle
18”
34” to 35”
0° to 15°
45,7 cm
86,4 cm - 88,9 cm
0° to 15°
Cardiac Chair
• Standard Cardiac Chair Position
• Enhanced Cardiac Chair Position
Head: 65°, Seat: 17°, Foot: 30°, Trend: 3°
Head: 70°, Seat: 19°, Foot: 47°, Trend: 3°
Fowler Length 36.5” 92,7 cm
Bed Lift
System
Height (high) to top of litter 31” 78,7 cm
Height (low) to top of litter 16” 40,6 cm
Trendelenburg/Reverse Trendelenburg 12°
Bed Lift Time 35 seconds maximum from lowest to highest position
Scale System Capacity 550 lbs 250 kg
Accuracy:
• For weight from 100 lb to 550 lb
• For weight from 100 lb to 550 lb
• For weight under 100 lb
• For weight under 100 lb
+/- 2% when in Trendelenburg or Reverse Trendelenburg
+/- 1% when Flat
+/- 2 lb when in Trendelenburg or Reverse
Trendelenburg
+/- 1 lb when Flat
CPR System Speed to level bed from any position
• Fowler
• Foot
• Seat
15 seconds
60 seconds
30 seconds
Drive System Speed (Optional ZOOM
®
Drive)
• Forward
• Backwards
3.6 mph
2.5 mph
5.8 km/h
4.0 km/h
