Stryker 2141 User Manual

English
1-44 2131-009-005 REV A www.stryker.com
Return To Table of Contents
Footboard Operation Guide
Angle History
Close
Reset
HOB 30
History
Angle Last 12h Last 24h
0 ~ 9° 12:00 24:00
10 ~ 19° 12:00 24:00
20 ~ 29° 12:00 24:00
30 ~ 39° 12:00 24:00
40 ~ 49° 12:00 24:00
50 ~ 59° 12:00 24:00
60 ~ 69° 12:00 24:00
70 ~ 79° 12:00 24:00
80 ~ 89° 12:00 24:00
Head of Bed
Close
Jul. 22, 2003 09:22 AM
Angle
Duration
20°
02h24min
Angle
History
Figure 8.5
Figure 8.6
Figure 8.7
History
Close
Bed Height
Scale Head of Bed
History Button
When the “History” button is pressed on the
Options screen, Figure 8.5 will be displayed.
When the “Scale” button is pressed, the Weight
History screen appears (see pg. 32, Fig. 5.6).
When the “Head of Bed” button is pressed
on the Options screen, Figure 8.6 will be
displayed.
The “Head of Bed History” displays the head’s
angle of the bed for the last 24 hours.
When the “Angle History” button is pressed,
on the Head of Bed screen, Figure 8.7 will be
displayed.
MAIN MENU: OPTIONS (CONTINUED)
