1-62 2131-009-005 REV A www.stryker.com
Return To Table of Contents
Dual Head End Permanent I.V. Pole - FA64202
The Optional Dual Head End I.V. Pole is permanently attached and equipped with a telescopic pole. The telescopic
pole is an extension which provides a second height position. The Permanent I.V. Pole can be folded and stored.
INSTALLATION
Required Tools:
• 3/8” Drive Ratchet
• 1/2” Socket
1. Using bolt (D) and washer (C), secure the I.V. pole (A) into the appropriate opening to the left of the head of the
bed.
2. Using bolt (D) and washer (C), secure the I.V. pole support (B) in the appropriate opening to the right of the head
of the bed.
Note: The bolt used is coated with “Scotch Grip”. This type of bolt must be replaced by a new identical
bolt if it is removed following a first installation.
A
B
C
D
