Pendant with Motion Control Only - FA64209
The Optional Pendant with Motion Control was designed to give the patient control over the bed’s motion.
WARNING
The Weigh system as well as the Bed Exit system must be adjusted if this accessory is added when either system is
in function. Refer to the “Add/Remove Equipment” from the bed procedure on page 33.
INSTALLATION
Required Tools: None
1. Plug the cable connector into connector (A) located on the right of the upper frame.
2. Install the removable pendant on the right foot siderail.
Note: Illustration may differ according to bed model.
A
Insert the removable pendant
in in this space. Slide it until it
clips.
Motion Control
